Pld and Cpld Based Traffic Light Control System

We have designed the traffic controller using both CPLD and PLD. Then we have taken the real time waveform as well as the simulated waveform for different frequencies. The Digital Storage Oscilloscope (DSO).was used to generate the real time wave from the traffic controllers. The results from the real time waveform clearly illustrates that CPLD has the better performance over the PLD technology. Further more we have designed complex circuits for automated detection of railway crossing and A Five road junction controlling Traffic light system.
